Fabrication of an Aluminum Alloy Bracket Assembly for a Military Application

Fabrication of an Aluminum Alloy Bracket Assembly for a Military Application
Fabrication of an Aluminum Alloy Bracket Assembly for a Military Application

When a customer in the defense industry needed an internal mount for a military vehicle, Dresco Machining & Fabrication was contracted to employ our advanced metal fabrication capabilities. To fabricate this assembly, two types of aluminum alloy were used: 5052-H32 with a thickness of .125" to .250", and 6061-T6 with a thickness/overall diameter of .750". These components were constructed under stringent quality control, with dimensional and visual inspection performed throughout the process. Processes applied for fabrication included Waterjet cutting, hydraulic press bending and forming, CNC turning, and welding.

To finish this assembly, we deburred, painted, and marked each part, adhering to the customer's specifications detailed in 2D CAD drawings throughout the process.

The final product met a host of military and industry standards, including ASTM B209, ASTM B221, and MIL-DTL-5541 Type II Class 1A, among others. Our plant was able to produce 111 of these assemblies in a turnaround time of just 6 to 8 weeks for our client in Auburn, Washington.

To find out more about this project or to learn how Dresco can put its expertise to work for you, please see the table below or contact us directly.

Request A Quote

Highlights of this Aluminum Bracket Fabrication Project

Aluminum Alloy Bracket Fabrication
Military Vehicle-Internal Mount
Fabrication Capabilities Applied/Processes
Primary:
Waterjet Cutting
Hydraulic Press Bending/Forming
CNC Turning
Welding
Secondary:
Painting
Part Marking
Deburring
Equipment Used to Manufacture Part
Waterjet
Press Brake
Welder
Tightest Tolerances
.012''
Material Used
Aluminum Alloy 5052-H32 ASTM B209
  • Thickness: 0.125" to 0.250"
Aluminum Alloy 6061-T6 ASTM B221
  • Thickness/OD: ø 0.750"
Material Finish
Painted
  • MIL-DTL-5541 Type II Class 1A
  • FED-STD-595
  • MIL-STD-764 Type G
In Process Testing/Inspection Performed
Dimensional Inspection, Visual Inspection
Industry for Use
Military/Defense
Volume
111
Delivery/Turnaround Time
6-8 weeks
Delivery Location
Auburn, Washington
Standards Met
Customer Specifications, 2D CAD Drawings
Product Name
Bracket Assembly
